{"Number of Flutes":"2","Drilling L/D Ratio (xD)":["11","12","10","9","8","7","6"],"Diameter - Inch (D)":["0.0785","0.081","0.082","0.086","0.089","0.0935","0.09375","0.096","0.098","0.0995","0.1015","0.104","0.1065","0.109375","0.11","0.111","0.113","0.116","0.12","0.125","0.1285","0.136","0.1405","0.140625","0.144","0.147","0.1495","0.152","0.154","0.15625","0.157","0.159","0.161","0.166","0.1695","0.171875","0.173","0.177","0.18","0.182","0.185","0.1875","0.189","0.191","0.1935","0.196","0.199","0.201","0.203125","0.204","0.2055","0.209","0.213","0.21875","0.221","0.228","0.234","0.234375","0.238","0.242","0.246","0.25","0.257","0.261","0.265625","0.272","0.277","0.28125","0.29","0.295","0.296875","0.302","0.3125","0.316","0.323","0.328125","0.332","0.339","0.34375","0.348","0.358","0.359375","0.368","0.375","0.377","0.386","0.390625","0.397","0.404","0.40625","0.413","0.421875","0.4375","0.453125","0.46875","0.484375","0.5","0.53125","0.5625","0.578125","0.59375","0.625","0.65625","0.6875","0.71875","0.75"],"Overall Length - Metric (L)":["57","60","63","66","71","73","74","77","80","84","87","90","92","95","104","107","109","112","115","119","120","123","127","130","133","134","138","145","148","151","153","156","159","162","164","167","182","199","210","235","216"],"Flute Length - Metric (FL)":["25","28","31","34","36","38","41","44","47","50","53","55","58","61","63","66","69","73","74","77","80","84","87","88","92","95","98","100","103","106","109","111","114","122","131","142","149"],"Shank Diameter - Inch (d)":["0.125","0.1875","0.25","0.375","0.5","0.625","0.75","0.875"],"Diameter - Metric (D)":["1.994","2.057","2.083","2.184","2.261","2.375","2.381","2.438","2.489","2.527","2.578","2.642","2.705","2.778","2.794","2.819","2.87","2.946","3.048","3.175","3.264","3.454","3.569","3.572","3.658","3.734","3.797","3.861","3.912","3.969","3.988","4.039","4.089","4.216","4.305","4.366","4.394","4.496","4.572","4.623","4.699","4.763","4.801","4.851","4.915","4.978","5.055","5.105","5.159","5.182","5.22","5.309","5.41","5.556","5.613","5.791","5.944","5.953","6.045","6.147","6.248","6.35","6.528","6.629","6.747","6.909","7.036","7.144","7.366","7.493","7.541","7.671","7.938","8.026","8.204","8.334","8.433","8.611","8.731","8.839","9.093","9.128","9.347","9.525","9.576","9.804","9.922","10.084","10.262","10.319","10.49","10.716","11.113","11.509","11.906","12.303","12.7","13.494","14.288","14.684","15.081","15.875","16.669","17.463","18.256","19.05"],"Helix Angle - Degree":"30","Diameter - Wire Gage (D)":["47","46","45","44","43","42","41","40","39","38","37","36","35","34","33","32","31","30","29","28","27","26","25","24","23","22","21","20","19","18","17","16","15","14","13","12","11","10","9","8","7","6","5","4","3","2","1"],"Short Description":"Cobalt-HSS Drills for Drilling in a Variety of Materials","Web Literature 1":["8002024CA-DR,197|8002024CA-DRT,48","8002024CA-DR,198|8002024CA-DRT,48"],"Cutting Diameter Tolerance Specification":"h8","List Name":"EX-GDR","Web Literature 4":"800387CA","Brand":"EX-GOLD","Substrate":"HSS-CO","Product Overview":"HSS-Co, Jobber Length, TiN Coating","Feature 2":"HSS-Cobalt Substrate","Hardened Steels : 35 HRC":"H; Good","Cast Iron":"K; Good","Low Carbon Steel : 1010; 1018":"P; Best","Benefit 2":"Added hardness versus ordinary HSS, yet exceptional toughness provides exceptional versatility in any application.","Aluminum : Casting":"N; Good","Medium Carbon Steel : 1035; 1045":"P; Best","Units":"Inch","Stainless Steels : 17-4PH":"M; Good","Benefit 3":"Increased hardness and lubricitiy inceases wear resistance thereby extending tool life.","Coolant Thru":"No","High Carbon Steel : 1065":"P; Good","Benefit 1":"No center drills neeeded. Achieves high accuracy while reducing drill thrust force for longer tool life.","Alloy Steels : 4140; 4340":"P; Best","Feature 1":"Radial Point Thinning","Cutting Direction":"RH","Die Steels":"P; Best","View Catalog Page":"Here","View Speed and Feed Page":"Here","Helix Direction":"RH","Surface Treatment":"TiN","Feature 3":"Titanium Nitride Coating","Cutting Diameter Tolerance - Inch":["+0 / -0.0006","+0 / -0.0007","+0 / -0.0009","+0 / -0.0011","+0 / -0.0013"],"Length of Cut - Specification":["TAPER","EXTRA LONG"],"Cutting Diameter Tolerance - Metric":["+0 / -0.014","+0 / -0.018","+0 / -0.022","+0 / -0.027","+0 / -0.033"],"Full Description":"The Ex-Gold drill line is famous worldwide for its incredible performace in nearly all material families. From cast iron and hardened alloy steel to manual machines or CNC controls, this drill has the toughness and durability to perform. Available in stub and jobber lengths in a complete stocked size offering.","Point Thinning":["X Thinning","R Thinning"],"Point Angle - Degree (α)":"130","Diameter - Fractional Size (D)":["3/32","7/64","1/8","9/64","5/32","11/64","3/16","13/64","7/32","15/64","1/4","17/64","9/32","19/64","5/16","21/64","11/32","23/64","3/8","25/64","13/32","27/64","7/16","29/64","15/32","31/64","1/2","17/32","9/16","37/64","19/32","5/8","21/32","11/16","23/32","3/4"],"Diameter - Letter Size (D)":["A","B","C","D","E","F","G","I","J","L","M","N","O","P","Q","R","S","T","U","V","W","X","Y","Z"],"Diameter-Sizes":"0.0785\" - 19.05mm","Flute-Sizes":"25mm - 149mm","Neck-Sizes":"-","Taper-Sizes":"-","Overall-Sizes":"57mm - 235mm","Shank-Sizes":"0.125\" - 0.875\"","Images":["https://res.cloudinary.com/osg-usa-inc/image/upload/f_jpg,q_auto//Products%2FDrilling%2FSolid%2FJobber%20Drills%2FList%201500/Drills_-_Drill_-_EX-GOLD_-_List_1500_-_Catalog"],"Friendly Name":"1500"}
