DRILLING/INDEXABLE - DRILLING/CENTERING AND CHAMFERING/78034

Indexable Centering and Chamfering Cutter

EDP: 7803404
PLDS11R002SS16-L120DEG
Description
Description
PHOENIX PLDS is a versatile series of indexable tools for spot drilling, countersinking & chamfering
Features & Benefits
Coolant hole Improves chip evacuation and cooling effect on the cutting edge
Economical 3-corner triangle insert Combines chipping resistance and sharpness
Highly rigid negative chamfer tip Enables difficult centering operations
Negative rake angle Suppresses burrs on the work surface
Globally Stocked
SUBSTITUTE PRODUCT

List Price

IL: 0 In stock

CA: 0 In stock

MOQ: 1

Add to List
Diameter - Metric (D)17.3
Diameter Min - Metric (D Min)2.4
Diameter Max - Metric (D Max)16
Length of Cut - Metric (Lc)4
Neck Length - Metric (L1)30
Overall Length - Metric (L)200
Shank Diameter - Metric (d)16
Shank Length - Metric (l2)170
Number of Flutes1
SubstrateTOOL STEEL
Body TypeCylindrical Shank
Helix DirectionRH
Cutting DirectionRH
Coolant ThruYes
Applicable InsertTPKT11
Product CategoryIndexable Insert Drill
View Catalog PageHere
View Speed and Feed PageHere
