52601005 - PSE15R125ASF16-3

90 Degree indexable shoulder cutter - Screw-Fit

EDP: 52601005

PSE15R125ASF16-3

Description

Description

PHOENIX SF is a series of modular indexable end mills, with PSE, PRC, PHC, PFB and PFR styles for a variety of applications.

Features & Benefits

Straight shank, BT taper and HSK taper arbors Capable of extended overhangs

Uses same inserts as PHOENIX end mill and facemill styles More economical and simplified insert management

End mill style, Inch and Metric Complete Offering

Modular body style Quick and easy to change system and provides milling flexibility

Stocked

ALTERNATIVE PRODUCT

VIEW PRODUCT

IL: 11 In stock

CA: 0 In stock

MOQ: 1

Quantity:

Diameter - Inch (D)	1.25
Pilot Diameter - Inch (Da)	0.669
Flange Diameter - Inch (D2)	1.102
Length of Cut - Inch (Lc)	0.551
Overall Length - Inch (L)	1.575
Spanner Wrench	22
Substrate	TOOL STEEL
Number of Flutes	3
Applicable Insert	ZDKT15
Body Type	Screw Fit Head
Coolant Thru	Yes
Cutting Direction	RH
Thread Size - Metric (Dg)	M16
Units	Inch
View Catalog Page	Here
View Speed and Feed Page	Here
Notes	When using an insert with a corner radius of R2 or greater, the corner of the cutter body must be corrected. The body corner radius should equal insert radius minus one (example: if insert radius is R3, body radius should be R2).
