MILLING/INDEXABLE - MILLING/EXCHANGEABLE HEAD END MILLS/78035

OSG PHOENIX PXM SS/TP - COOLANT THROUGH

Exchangable head end mill series for superior surface finish

EDP: 48309005
PXMZ-C12SS12-S075CS-O
Description
Indexable_-_Mill_-_PHOENIX_PXM_-_List_78035_-_Exchangeable_Head_-_Arbor_-_Straight_Shank_-_Catalog
Description
PHOENIX PXM is an exchangeable head end mill series for superior surface finish and precision in a variety of applications.
Features & Benefits
Radial runout less than 15µm and axial repeatability ±30µm High accuracy and repeatability
2-face contact (end face and taper) and buttress thread Fast and highly rigid clamping
End mill style, Inch and Metric Complete Offering
OSG's proven cutting geometries and coatings High performance in a variety of applications and materials
Stocked
ALTERNATIVE PRODUCT
VIEW PRODUCT

IL: 0 In stock

CA: 0 In stock

Check availability

MOQ: 1

Add to List

Preview PDF

PDF generation may take time depending on details of the product.

Neck Diameter - Metric (d1)11.7
Neck Length - Metric (L1)25
Overall Length - Metric (L)75
Shank Diameter - Metric (d)12
SubstrateCarbide
Applicable Head - Metric12
Body TypeCylindrical Shank Carbide
Connection Size (Cs)C12
Coolant ThruYes
Cutting DirectionRH
Type3
UnitsMetric
View Catalog PageHere
NotesWrench included with body.
