OSG Patented Diamond Coated Taps for High SiC Aluminum, MMC, and Carbon Fiber
Non-Ferrous
Other Material
Non-Ferrous
Other Material
IL: 25 In stock
CA: 0 In stock
MOQ: 1
PDF generation may take time depending on details of the product.
| Thread Size - Metric | M5 |
| Thread Type | M |
| Pitch | 0.8 |
| Class of Fit | 6H |
| Chamfer Type | Modified Bottom (2.5P) |
| Major Diameter - Metric | 5 |
| Thread Length - Metric (Lc) | 16 |
| Tap Drill Size Min - Metric | 4.134 |
| Tap Drill Size Max - Metric | 4.334 |
| Neck Length - Metric (L1) | 24 |
| Overall Length - Metric (L) | 60 |
| Shank Diameter - Metric (d) | 5.5 |
| Square Length - Metric (Ik) | 7 |
| Square Width - Metric (k) | 4.5 |
| STI Thread | No |
| Substrate | Carbide |
| Surface Treatment | DIAMOND |
| Coolant Thru | No |
| Number of Flutes | 4 |
| Cutting Direction | RH |
| Helix Angle - Degree | 0 |
| Interrupted Thread | No |
| View Catalog Page | Here |
| STP Drawing | Download |
