THREADING/STYLE/SPIRAL FLUTE/307

Coolant-Through Taps Designed for Stainless Steel

EDP: 30701808
1/4-20 H5 3FX MOD-BOTT EXOTAP VA3 DIN OH V
Description
P

Steel

Medium Carbon Steel : 1035; 1045
Low Carbon Steel : 1010; 1018
High Carbon Steel : 1065

Good
Best
M

Stainless Steel

Stainless Steels : 300
Stainless Steels : 400
Stainless Steels : 17-4PH

Good
Best
P

Steel

Medium Carbon Steel : 1035; 1045
Low Carbon Steel : 1010; 1018
High Carbon Steel : 1065

Good
Best
M

Stainless Steel

Stainless Steels : 300
Stainless Steels : 400
Stainless Steels : 17-4PH

Good
Best
Description
EXOTAP VA-3 is the premium solution for tapping in stainless steels.
Features & Benefits
HSSE material Increased wear resistance
OSG V-Coating Increased hardness, lubricity & wear resistance
Spiral Flute For blind hole applications
Steam Oxide surface treatment S/O increases mechanical lubricity
Stocked
ALTERNATIVE PRODUCT

List Price

IL: 51 In stock

CA: 0 In stock

MOQ: 1

Add to List
Thread Size - Inch1/4
Thread TypeUNC
Threads Per Inch20
Thread LimitH5
Chamfer TypeModified Bottom (2.5P)
Major Diameter - Inch0.25
Thread Length - Inch (Lc)0.402
Tap Drill Size Min - Inch0.196
Tap Drill Size Max - Inch0.207
Neck Length - Inch (L1)1.181
Overall Length - Inch (L)3.15
Square Length - Inch (Ik)0.3125
Shank Diameter - Inch (d)0.255
Square Width - Inch (k)0.191
STI ThreadNo
SubstrateHSSE
Surface TreatmentV
Coolant ThruYes
Number of Flutes3
Cutting DirectionRH
Helix Angle - Degree45
Helix DirectionRH
Interrupted ThreadNo
View Catalog PageHere

Downloads


Basic 3D Model (STP)

2D Drawing(DXF)
