Advanced Performance Highly Efficient Multi-Purpose Forming Tap
Steel
Stainless Steel
Non-Ferrous
Hardened Steel
Heat Resistant Super Alloy
Steel
Stainless Steel
Non-Ferrous
Hardened Steel
Heat Resistant Super Alloy
MOQ: 1
PDF generation may take time depending on details of the product.
Thread Size - Metric | M10 |
Thread Type | M STI |
Pitch | 1.5 |
Thread Limit | D8 |
Chamfer Type | Modified Bottom (2.5P) |
Major Diameter - Metric | 11.948557 |
Thread Length - Metric (Lc) | 15 |
Tap Drill Size Min - Metric | 11.098 |
Tap Drill Size Max - Metric | 11.255 |
Neck Length - Metric (L1) | 49.1 |
Overall Length - Metric (L) | 100 |
Shank Diameter - Metric (d) | 9.322 |
Square Length - Metric (Ik) | 11.113 |
Square Width - Metric (k) | 6.985 |
STI Thread | Yes |
Substrate | VC-10 |
Surface Treatment | VI |
Coolant Thru | No |
Cutting Direction | RH |
Interrupted Thread | No |
View Catalog Page | Here |
