THREADING/STYLE/STRAIGHT FLUTE/328,THREADING/STYLE/PIPE TAPS/328 - PIPE

Ideal for Tapping Mold Steel

EDP: 1736000
1/8-27 NPT Lg.Shk. EXOTAP-MOLD
Description
P

Steel

Alloy Steels : 4140; 4340
Die Steels
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045
High Carbon Steel : 1065

Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400

Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC
Hardened Steels : 35-45 HRC

Good
Best
P

Steel

Alloy Steels : 4140; 4340
Die Steels
Low Carbon Steel : 1010; 1018
Medium Carbon Steel : 1035; 1045
High Carbon Steel : 1065

Good
Best
M

Stainless Steel

Stainless Steels : 17-4PH
Stainless Steels : 300
Stainless Steels : 400

Good
Best
H

Hardened Steel

Hardened Steels : 35 HRC
Hardened Steels : 35-45 HRC

Good
Best
Description
EXOTAP MOLD is the premium pipe tap solution for threading die steels such as P20 and H13.
Features & Benefits
HSS-CO material Increased toughness and wear resistance
NPT or ANPT For standard NPT tapered pipe applications
Stocked
ALTERNATIVE PRODUCT

List Price

Loading...

MOQ: 1

Add to List
Thread Size - Inch1/8
Thread TypeNPT, ANPT
Threads Per Inch27
Major Diameter - Inch0.125
Thread Length - Inch (Lc)0.751
Tap Drill Size Min - Inch0.332
Neck Length - Inch (L1)0.992
Overall Length - Inch (L)2.125984
Square Length - Inch (Ik)0.375
Shank Diameter - Inch (d)0.4375
Square Width - Inch (k)0.328
STI ThreadNo
SubstrateHSS-CO
Surface TreatmentBRIGHT
Coolant ThruNo
Number of Flutes4
Cutting DirectionRH
Helix Angle - Degree0
Interrupted ThreadNo
View Catalog PageHere
NotesOther coatings are available upon request.

Downloads


Basic 3D Model (STP)

2D Drawing(DXF)
