THREADING/STYLE/STRAIGHT FLUTE/16615

Advanced Performance Coolant-Through Taps Designed for Cast Iron

EDP: 1661500200
#12-24 H3 3FL 1.5P A BRAND A-CHT
Description
K

Cast Iron

Cast Iron

Good
Best
N

Non-Ferrous

Aluminum : Casting

Good
Best
K

Cast Iron

Cast Iron

Good
Best
N

Non-Ferrous

Aluminum : Casting

Good
Best
Description
A Brand A-CHT is an Advanced Performance Carbide Coolant-Through Taps for Cast Iron and Aluminum Alloy
Features & Benefits
Larger Oil Hole Design Excellent coolant flow
Bright finish Greater performance in non-ferrous materials
Ultra-Fine Grain Carbide For high wear resistance and toughness
Stocked
ALTERNATIVE PRODUCT

List Price

Loading...

MOQ: 1

Add to List
Thread Size - NumberNo. 12
Thread TypeUNC
Threads Per Inch24
Thread LimitH3
Chamfer TypeBottom (1.5P)
Major Diameter - Inch0.216
Thread Length - Inch (Lc)0.5
Tap Drill Size Min - Inch0.171
Tap Drill Size Max - Inch0.181
Neck Length - Inch (L1)0.945
Overall Length - Inch (L)3.15
Square Length - Inch (Ik)0.28125
Shank Diameter - Inch (d)0.22
Square Width - Inch (k)0.165
STI ThreadNo
SubstrateCarbide
Surface TreatmentBRIGHT
Coolant ThruYes
Number of Flutes3
Cutting DirectionRH
Helix Angle - Degree0
Interrupted ThreadNo
View Catalog PageHere
NotesOther coatings are available upon request. Reduce SFM 50% - 70% while using external coolant.

Downloads


Basic 3D Model (STP)

2D Drawing(DXF)
