Variable Helix Tap for Stainless Steel
Steel
Stainless Steel
Steel
Stainless Steel
IL: 7 In stock
CA: 8 In stock
MOQ: 1
PDF generation may take time depending on details of the product.
| Thread Size - Metric | M14 |
| Thread Type | M |
| Pitch | 2 |
| Thread Limit | D7 |
| Chamfer Type | Modified Bottom (2.5P) |
| Major Diameter - Metric | 14 |
| Thread Length - Metric (Lc) | 16 |
| Tap Drill Size Min - Metric | 11.835 |
| Tap Drill Size Max - Metric | 12.21 |
| Neck Length - Metric (L1) | 50.1 |
| Overall Length - Metric (L) | 110 |
| Shank Diameter - Metric (d) | 10.8966 |
| Square Length - Metric (Ik) | 12.7 |
| Square Width - Metric (k) | 8.1788 |
| STI Thread | No |
| Substrate | HSSE |
| Surface Treatment | TiN |
| Coolant Thru | No |
| Number of Flutes | 3 |
| Cutting Direction | RH |
| Helix Angle - Degree | 45 |
| Helix Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| STP Drawing | Download |
| Notes | *Recommended drill is ADO-SUS drills for stainless steel. |
