Variable Helix Tap for Stainless Steel
Steel
Stainless Steel
Steel
Stainless Steel
MOQ: 1
PDF generation may take time depending on details of the product.
| Thread Size - Inch | 5/8 |
| Thread Type | UNC |
| Threads Per Inch | 11 |
| Thread Limit | H3 |
| Chamfer Type | Modified Bottom (2.5P) |
| Major Diameter - Inch | 0.625 |
| Thread Length - Inch (Lc) | 0.728 |
| Tap Drill Size Min - Inch | 0.527 |
| Tap Drill Size Max - Inch | 0.546 |
| Neck Length - Inch (L1) | 2.126 |
| Overall Length - Inch (L) | 4.331 |
| Square Length - Inch (Ik) | 0.5625 |
| Shank Diameter - Inch (d) | 0.48 |
| Square Width - Inch (k) | 0.36 |
| STI Thread | No |
| Substrate | HSSE |
| Surface Treatment | TiN |
| Coolant Thru | No |
| Number of Flutes | 3 |
| Cutting Direction | RH |
| Helix Angle - Degree | 45 |
| Helix Direction | RH |
| Interrupted Thread | No |
| View Catalog Page | Here |
| STP Drawing | Download |
| Notes | *Recommended drill is ADO-SUS drills for stainless steel. |
